Product Features:
Real-time contamination level monitoring (NAS or ISO standards).
Ultrasonic vibration for bubble removal to ensure testing accuracy.
Automatic adjustment of monitoring and purification operation modes.
Ultra-precision filtration with β₃=929.
Removes solid impurities, moisture, oxides, degradation substances, and oil sludge paint film.
Motor overload and phase sequence protection, high oil temperature alarm, filter saturation alarm.
Benefits:
Enables proactive oil condition management.
Prevents unexpected equipment failures.
Optimizes filter replacement intervals and reduces waste.
Ensures consistent oil cleanliness and system reliability.
Specifications:
Environmental Conditions: Same as standard series (Altitude ≤1000m, Temp -20℃~60℃, etc.).
| Device Model | AITAI-IOM103-1RC | AITAI-IOM103-2RC | AITAI-IOM305-1RC |
| Flow Rate | 9L/min | 18L/min | 30L/min |
| Motor Power | 0.4kW | 0.75kW | 0.75kW |
| Operating Voltage | AC380V 50Hz Three-phase four-wire | ||
| Inlet/Outlet Diameter | Rc1/2 | Rc1 | Rc1 |
| Operating Pressure | 0.5MPa | ||
| Debubbling Device | Optional (Q) | ||
| Contamination Standard | NAS/ISO level | ||
| Filter Precision | β3=929 | ||
| Filter Element Quantity | 3 | 6 | 5 |
| Overall Dimensions | 1010 * 503 * 1213 | 1312 * 503 * 1213 | 1325 * 580 * 1383 |
| Weight | 110.5kg | 136kg | 253.5kg |
AITAI, founded in 2013, is a high-tech enterprise focused on TEL. As the strategic partner of 3R Group Japan, we provides ultra-precision purifiers, on-site solutions, and oil testing& analysis, Serving metallurgy, automobile, power, marine, petrochemical, and machinery industries.
