Product Features:
Simplified design focusing on essential oil transfer and filtration functions.
Includes pump, filter housing, tank, and basic controls.
Suitable for routine oil changes, top-ups, and basic contamination control.
Compact and maneuverable for plant or workshop use.
Benefits:
Affordable solution for basic oil maintenance needs.
Reduces manual handling and improves oil change efficiency.
Helps maintain oil cleanliness and equipment reliability.
Easy to operate and maintain.
Specifications:
(Note: Specific specs not detailed in provided catalog. Generally includes smaller capacity tanks, standard filtration options, and basic pump systems compared to OFC series.)
|
Device Model |
AITAI-OFCL-50（20） |
AITAI-OFCL-100（20） |
||||
|
Flow Rate |
50L/min |
100L/min |
||||
|
Inlet/Outlet Diameter |
Rc1-1/4 |
|||||
|
Motor Power |
2.2kW |
|||||
|
Operating Voltage |
AC380V 50Hz three-phase four-wire |
|||||
|
Weight |
95.5kg |
99.5kg |
||||
|
Overall Dimensions |
670 * 625 * 1228 |
|||||
|
Filter Element Material |
Fiberglass |
|||||
|
Filter Element Precision |
1μm |
3μm |
5μm |
10μm |
20μm |
|
|
Filter Element Model |
1600LL |
3600LL |
5600LL |
10600LL |
20600LL |
|
