Product Features:
Uses a unique vacuum tower structure without heating to remove large amounts of water and bubbles.
Avoids oil oxidation and degradation caused by high-temperature heating.
Can be combined with optional particle filtration (2RA/2RB).
High efficiency in removing free water, dissolved water, and entrapped air.
Benefits:
Extends oil service life by preventing thermal degradation.
Effectively removes water without damaging oil properties.
Energy-efficient operation (no heating required).
Improves system reliability by eliminating water-induced failures.
Specifications:
Performance: Free water 100%; Bubbles in oil 100%; Dissolved water 80%.
Environmental Conditions: Standard operating environment as other series.
| Model | TRVS-30E | TRVS-30E-2RA | TRVS-30E-2RB | TRVS-70E |
| Flow Rate | 30L/min | 70L/min | ||
| Applicable Viscosity Range | 10～680mm2/s | 10～680mm2/s | ||
| Vacuum level | -0.06MPa | -0.06MPa | ||
| Inlet/Outlet Diameter | Rc1-1/4 | Rc1-1/2 ；Rc1-1/4 | ||
| Vacuum Pump Power | 1.5kW | 2.2kW | ||
| Oil Pump Power | Suction pump: 0.75kW Discharge pump: 0.75kW | Suction pump: 2.2kW Discharge pump: 4.0kW | ||
| Operating Voltage | AC380V 50Hz three-phase four-wire | |||
| Precision Filter Element Quantity | None | 2 | 8 | None |
| Paint Film Filter Bag Quantity | None | None | 2(optional) | None |
| Overall Dimensions | 1461 * 620 * 1526 | 1708 * 803 * 1665 | 1708 * 803 * 1665 | 2000 * 1074 * 2366 |
| Weight | 357.5kg | 517kg | 512kg | 858kg |
